Description
Revolutionary Features of 7050 Laser Cutter
Integrated design, facilitating operation.
Automatic up&down worktable.
Wifi and autofocus features are included.
Encloased work space and linear rail.
Lid open safety protection.
3-color tower light status indicator.
Ruida control system. Compatible with LightBurn software.
7050 Laser Cutting Machine Parameters
| Model | 7050 (700mm*500mm) |
| Laser Source | 40W, 60W, 80W |
| Max. Engraving Speed | 1200mm/s |
| Z Axis Travel | 150mm |
| Motor Option | High speed stepper motor |
| Controller | Ruida |
| Software | RDWorks or Lightburn(Paid software, need to buy it yourself) |
| Worktable | Blades, extra honeycomb table is optional |
| Environment Humidity | 5%~95% (No condensing) |
| File Formats | BMP.GIF.JPEG.PCX.TGA.TIFF.PLT.CDR.DWG.DXF |
| Power Input | 220V~240V 50Hz or 110V~130V 60Hz |
| Cooling Method | Water Chiller Cooling |
| Air Assist and Fume Exhauster | Integrated in the machine chassis |
| Machine Gross Weight | 160KG |
| Machine Dimension | 1200*880*530mm |
Useful Optional Features
Rotary Device
Assistant for cylindrical objects engraving.
Fume Extraction System
Compulsory accessory for indoor fume exhausting or environmental proection required space.
