The CDWG 90W–200W Glass CO2 Laser Tube is designed for compatible CO2 laser engraving and cutting machines. Available across a range of power ratings, it can support applications such as cutting and engraving acrylic, wood, and other suitable non-metallic materials. Before purchasing, confirm the tube’s rated power, dimensions, mounting requirements, cooling method, and compatibility with your laser power supply and machine.
| TYPE | Full Length (mm) | Min Power (W) | Max Power (W) | Outer Diameter (mm) | Testing Current (mA) | Warranty (Months) |
| 1250T7 | 1250±20 | 90 | 110 | 80/60 | 30 | 12 |
| 1400T7 | 1450±20 | 110 | 125 | 80/60 | 30 | 12 |
| 1600S7 | 1600±20 | 120 | 135 | 80/60 | 30 | 12 |
| 1600F7 | 1680±20 | 130 | 155 | 80/60 | 30 | 10 |
| 1700H7 | 1750±30 | 145 | 165 | 80/60 | 30 | 10 |
| 1800U7 | 1850±30 | 150 | 180 | 100/80/60 | 30 | 10 |
| 2000K7 | 2050±30 | 170 | 200 | 100/80/60 | 30 | 10 |
